Sunhans FDD Tdd 4G Wireless CPE Indoor WiFi Router with RJ45 300Mbps High Speed
Sunhan CPE Wireless 4G LTE High Speed 300Mbps WiFi Router with SIM Card SlotMain futures :Support 4G network,LTE bands can be customizedSupport VOIP with RJ11 port4X4 DL_MIMO Internal antennaSupport web managementSupport network data traffic statistics .Support more than 32 WIFI devices online simul......
Send Inquiry
Product Description
Sunhan CPE Wireless 4G LTE High Speed 300Mbps WiFi Router with SIM Card Slot
Main futures :
Parameters:
About us
Our Service:
♦ Test process : every items will be testing before shipping, to make sure the quality.
♦ Short leading time: 1-2.5 working days for samples or small order, 10-15 working days for bulk order.
♦ One year warranty: for you without trouble of after-sales maintenance.
♦ Quality Guarantee: Return rate is only 0.001.
♦ Support small orders: help your business from small to big.
♦ OEM & ODM are welcome.
Main futures :
- Support 4G network,LTE bands can be customized
- Support VOIP with RJ11 port
- 4X4 DL_MIMO Internal antenna
- Support web management
- Support network data traffic statistics .
- Support more than 32 WIFI devices online simultaneously.
Parameters:
| SHFi4G8X8 | Technical specifications |
| 4G Platform | GCT GDM7243QT |
| Qualcomm MDM9225 | LTE-FDD/ TDD-LTE |
| LTE | Option 1: FDD:B3/B7/B20 Option 2: TDD:B34/B38/B39/B40/B41 Option 3: TDD: B42/B43 Please confrim your frequencies, frequencies can be customized |
| Rate level | CAT6 DL:300Mbps / UL:50Mbps |
| Transmitting power | 23dBm |
| Antenna | Internal antenna,Gain>3db |
| WiFi | |
| WiFi Band | 2.4GHz,802.11b/g/n |
| WiFi Rate | Highest rate 300Mbps |
| WiFi Standard | IEEE 802.11b/g/n |
| WiFi RF Characteristics | Highest transmit power 22dBm,sensitivity is better than -77dBm |
| Number of linking users | Maximum 32 user connected |
| CSFB | support |
| Network Features | |
| Networking protocols | PPTP,L2TP,PPPoE,DHCP,Client/Server,NAPT,NTP |
| High-speed router | Built-in DHCP Server,DNS Clinet,support NAT |
| Dialing function | Manual dialing,autodialing,PPPOE dialing |
| SIM card Features | Support 1.8V/3V powered SIM/USIM card,Support encryption card,Support |
| Management | |
| Web smart | support |
| Centralized network management | support |
| TR069 | support |
| Remote Upgrade | support |
| Security | |
| Security Features | Support port filtering, IP filtering, MAC filtering, URL filtering, MAC address binding |
| Speed control | Support UL and DL speed limit , port speed limit |
| Hardware | |
| LAN/WAN | RJ-45x1 (10/100/1000Mbps ethernet port) |
| FXS | RJ-11x1 |
| PSU | DC2.0 5V / 2A |
| Power | 10W |
| Light | Power,WiFi, VoIP,LTE signal,Ethernet |
| Physical Characteristics | |
| Working temperature | -5~50ºC |
| Stock temperature | -40~85ºC |
| Huminity | 5~95% |
