Lte Tdd FDD 3G/4G Router with SIM Slot 2.4G 300mpbs 4 Ethernet Ports WiFi Router
Sunhans 2G 3G 4G LTE Indoor Wireless CPE 300Mbps Powerful Network Desktop WiFi Router with RJ11 portMain futures :Support 2G/3G/4G network,LTE bands can be customizedQualcomm MDM9207+QCA6174 chipsetSupport VoLTE/VOIP/CS Domain voice with RJ11 port4X 10/100/1000Base Ethernet portSupport IEEE 802.11 b......
Send Inquiry
Product Description
Sunhans 2G 3G 4G LTE Indoor Wireless CPE 300Mbps Powerful Network Desktop WiFi Router with RJ11 port
Main futures :
Parameters:
About us
Our Service:
♦ Test process : every items will be testing before shipping, to make sure the quality.
♦ Short leading time: 1-2.5 working days for samples or small order, 10-15 working days for bulk order.
♦ One year warranty: for you without trouble of after-sales maintenance.
♦ Quality Guarantee: Return rate is only 0.001.
♦ Support small orders: help your business from small to big.
♦ OEM & ODM are welcome.
Main futures :
- Support 2G/3G/4G network,LTE bands can be customized
- Qualcomm MDM9207+QCA6174 chipset
- Support VoLTE/VOIP/CS Domain voice with RJ11 port
- 4X 10/100/1000Base Ethernet port
- Support IEEE 802.11 b/g/n standard ,WiFi rate up to 300Mbps
- Support web management
- Support network data traffic statistics .
- Support more than 32 WIFI devices online simultaneously.
Parameters:
| SHFi4G8X5 | Technical specifications |
| 4G Platform | Qualcomm MDM9207 |
| Qualcomm MDM9225 | LTE-FDD/ TDD-LTE/ WCDMA |
| LTE | FDD:B1/B3/B5/B7/B8/B28 TDD:B40 Please confrim your frequencies, frequencies can be customized |
| 3G/2G | WCDMA:B1/B5/B8 GSM: B2/B3/B5/B8 |
| Rate level | CAT4 DL:150Mbps / UL:50Mbps |
| Transmitting power | 23dBm |
| Antenna | External antenna and internal antenna,Gain>3db |
| WiFi | |
| WiFi Band | 2.4GHz,802.11b/g/n |
| WiFi Rate | Highest rate 300Mbps |
| WiFi Standard | IEEE 802.11b/g/n |
| Number of linking users | Maximum 32 user connected |
| Network Features | |
| Networking protocols | PPTP, L2TP, IPSec, PPPoE, DHCP, Client/Server, NAPT, NTP |
| High-speed router | Built-in DHCP Server, DNS Client, support NAT |
| Dialing function | Manual dialing, autodialing, PPPOE dialing |
| SIM card Features | 2FF SIM card Support SIM/USIM/UIM,standard 6 PIN SIM card interface, Support 3V SIM card and 1.8V SIM card;internal push-push SIM slot |
| Management | |
| Web smart | support |
| Centralized network management | support |
| TR069 | support |
| Remote Upgrade | support |
| IPv4 | support |
| IPv6 | support |
| SIM Lock | support |
| DOS Attack | support |
| WAN Fallback to ETH | Manually |
| DMZ | support |
| Security | |
| Security Features | Support port filtering, IP filtering, MAC filtering, URL filtering, WiFi Black/White list |
| Hardware | |
| LAN/WAN | 4 10/100/1000Base automatic adaptive port |
| FXS | RJ-11x2 by paralleling(optional) |
| PSU | DC2.0 12V @ 1000mA |
| Power | <12W |
| Light | power,Signal,WiFi,WAN/LAN,Internet |
| ESD | ESD protection cirtuit;Contact±8KV,Air±10KV |
| Physical Characteristics | |
| Working temperature | -10~65ºC |
| Stock temperature | -20~85ºC |
| Huminity | ≤95% |
Package contents:
1 x Wireless 4G router
1 x Power adapter
1 x RJ45 cable
1 x User manual
1xBuild-in battery
