2021 New WiFi 4G Indoor Industrial Router Support Openwrt Function
2018 New WIFI 4G indoor industrial router support openWRT function Highlight1). 3G/4G LTE data transmission;2). Active auto connect;3). Embedded watchdog , Auto recovery;4). 2*2 4G/WIFI MIMO antenna;5). Integrate 3G/4G LTE,WIFI,GPS feature;6). 4G LTE. Support CAT 3, CAT 4, CAT 6 now.7). WIFI High q......
Send Inquiry
Product Description
2018 New WIFI 4G indoor industrial router support openWRT function
Highlight
1). 3G/4G LTE data transmission;
2). Active auto connect;
3). Embedded watchdog , Auto recovery;
4). 2*2 4G/WIFI MIMO antenna;
5). Integrate 3G/4G LTE,WIFI,GPS feature;
6). 4G LTE. Support CAT 3, CAT 4, CAT 6 now.
7). WIFI High quality performance without congestion;
8). 1 WAN/1 LAN or 2 LAN ports, One console port;
9). With SIM card slot;
10). Wide power supply: +6V/2.5A~+48V/0.5A
11). Remote management platform;
12). Firmware version: Linux or Openwrt;
13). Small size dimension:115mm*73mm*20mm
| Specification | |||
| ITEM | VERSION | Description | |
| CPU | MTK7628 | ||
| Memory | FLASH 8MByte, DDR2 64MByte | ||
| Network mode | 4G Version | FDD LTE, TDD LTE,HSPA+,WCDMA,GPRS,GSM | |
| 3G version | WCDMA,GPRS,GSM | ||
| EVDO,CDMA 1X | |||
| Frequency bands | 3G version | WCDMA | 850/1900MHz, 850/2100MHz & 900/2100MHz,GSM,850/900/1800/1900MHz |
| EVDO | 800MHz & 800/1900MHz | ||
| 4G Version | Version A. | LTE FDD. B2,4,5,17. UMTS. 850/1900MHz | |
| Version C. | LTE FDD. B1,3,7,8 .LTE TDD B38, B39, B40, B41. | ||
| UMTS. 900/2100MHz. | |||
| TD-SCDMA. 1880~1920MHz & 2010~2025MHz | |||
| GSM. 900/1800MHz | |||
| Version E. | LTE FDD. B1,3,7,8,20 ,LTE TDD B38, B40. | ||
| UMTS. 900/2100MHz. | |||
| GSM. 900/1800MHz | |||
| Version JC | LTE FDD. B1,B3,B8,B18,B19. LTE TDD. B41. | ||
| UMTS. B1,B6,B8. | |||
| GSM. 900/1800MHz | |||
| Version JE | LTE FDD. B1,B8 | ||
| UMTS. B1,B8 | |||
| GSM. 900/1800MHz | |||
| Version SA | LTE-FDD B1/B3/B4/B5/B7/B8/B28, LTE-TDD B38/B40/B41 | ||
| UMTS/HSDPA/HSPA+ B1/B2/B5/B8 | |||
| GSM/GPRS/EDGE B2/B3/B5/B8 | |||
| GPS | Optional, GPS/GNSS/BD,gpsOne Gen 8B;standalone;assisted,XTRA; | ||
| Data rates | |||
| 3G Router | WCDMA | DL 14.4Mbps, UL 5.76Mbps | |
| EVDO | DL 3.1Mbps, UL 1.8Mbps | ||
| 4G LTE router | LTE FDD | DL 100Mbps~300Mbps, UL 50Mbps | |
| LTE TDD | DL 50Mbps, UL 25Mbps | ||
| HSPA+ | DL 42Mbps, UL 5.76Mbps | ||
| TD-SCDMA | DL 2.8Mbps, UL 2.2Mbps | ||
| GPRS | Max. 85.6Kbps(DL), Max. 85.6Kbps(UL) | ||
| WIFI | 802.11b/g/n, 300Mbps | ||
| LAN | 2* LAN Ports, 100Mbps | ||
| Hardware interface | |||
| SIM card | 1*SIM card, Standard draw card interface, support 1.8V/3V SIM/UIM card, built-in ESD protection | ||
| UART | 1*RS232 port | ||
| Power supply | Input. +6V/2.5A~48V/0.5A,Standard Power Supply,DC +12V/1.5A | ||
| LED Indicator | SYS, Net, WAN, LAN,RSSI | ||
| RF connectors | SMA connector , 4G(female),WIFI(male),the characteristic impedance 50Ω . | ||
| Antenna | 2*2 4G/WIFI MIMO antenna; | ||
| Software | |||
| Security Encryption | Support WEP,WPA,WPA2 encryption ways | ||
| Watchdog | Embedded watchdog , System auto recovery; | ||
| Data link | Active auto connect; | ||
| Protocol | PPTP,L2TP,IPSEC VPN,Open VPN,GRE,TCP,UDP, DHCP,HTTP,DDNS,TR-069, HTTPS, SSH,SNMP etc. | ||
| VLAN | Support VLAN feature | ||
| Data backup | Double backup, keep data safe and reliable | ||
| Server | Remote management platform; | ||
| Operating system | Linux or OpenWRT | ||
| Environmental parameters | |||
| Conditions | Operating temperature | -40ºC - +75ºC | |
| Storage temperature | -45ºC - +80ºC | ||
| Operating humidity. | 5%-95% | ||
| Case | Aluminum Alloy Shell | ||
| Dimension | 115mm*73mm*20mm | ||
| Weight | 160g | ||
