NuBiz™ B1205FGenew iAN1200 series MSAN portfolio accommodates carrier-grade broadband access, telephony and data service interfaces in a single compact NGN platform, enabling operators to offer value added TRIPLE PLAY and broadband business services and migrate to NGN while maintaining the......
Send Inquiry
Product Description
Genew iAN1200 series MSAN portfolio accommodates carrier-grade broadband access, telephony and data service interfaces in a single compact NGN platform, enabling operators to offer value added TRIPLE PLAY and broadband business services and migrate to NGN while maintaining the traditional telephony services. MSAN B1200 product line includes high (iAN B1205F/B1205E), medium (iAN B1205 /B1205v) devices that offer the benefit of converged access with an integrated TDM migration, POTS termination, DSL, Media Gateway and Ethernet/ xPON uplinks on the same platform.
Overview - B1205F MSAN / MDU / DSLAM:
B1205F is a cost effective & versatile Digital Loop Carrier (DLC) and Multi Service Access Node (MSAN) optimal solution from Genew that provides a unique set of capabilities enabling service providers to deliver the most competitive triple play service offerings. It enables service providers to smoothly migrate to IP based next-generation applications while continuing to offer traditional TDM based services to customers.
The B1205F supports a range of technologies such as POTS, ADSL2/ADSL2+, VDSL2, SHDSL(EFM) which allows the service providers to offer highly interactive and bandwidth intensive applications. B1205F acts as a traditional TDM based DLC, IPDSLAM, Media Gateway platform rolled into one.
Specification - B1205F MSAN / MDU / DSLAM:
Size: 483mm (W) x 320mm (D) x 620mm (H)
Weight: 16.4 Kg
Mounting: 19" inch Rack mount, 14RU
Power: DC: -40V to -60V / Dual Redundancy
System Capacity
Single Chassis - Up to 1248 POTS (VoIP or V5)
Single Chassis - Up to 832 ADSL2+ ports
Single Chassis - Up to 416 IVD (ADSL2+ POTS combo)
Single Chassis - Up to 416 VDSL2
Single Chassis - Up to 312 SHDSL(EFM)
Cascading Chassis - Up to 3744 POTS (VoIP or V5)
Cascading Chassis - Up to 2496 ADSL2+ ports
Cascading Chassis - Up to 1248 IVD(ADSL2+ POTS combo)
Cascading Chassis - Up to 1248 VDSL2
Cascading Chassis - Up to 936 SHDSL(EFM)
Shelf Configuration
21 slots per chassis
2 slots for redundant Control & Switching Module (CSM in Master Shelf/EBAM in Slaver Shelf)
4 Flexible slots for:
- Peripheral Control Unit (PCU)
- E1 Module (E1M)
- Voice Packetization Module (VPM)
13 universal slots for Subscriber modules: FXS, ASL, VSL, IVD, HDSL
2 slots for redundant Power Modules (POW)
Management Capabilities
Netman 4000 OMC-A
North Bound Interface (NBI)
SNMP based network management.
Family - Genew Copper Access Network:
| Model | Description |
| iAN B1205F | 14U; Super high desity - 13 slots; Support cascading by TDM |
| iAN B1205E | 8U; High density - 10 slots - POTS, ADSL2/ADSL2+, VDSL2, SHDSL(EFM) |
| iAN B1205VE | 8U; High density - 10 slots - GPON, SHDSL, VDSL2 with vectoring and voice |
| iAN B1205V | 5U; Medium density - 5 slots - GPON, VDSL2 combo |
| iAN B1205 | 5U; High density - 5 slots - POTS, ADSL2/ADSL2+, VDSL2, SHDSL(EFM) |
| iAN B1202 | 2U; Low density - 4 slotss - POTS, (ADSL/ADSL2/ADSL2+ |
