Item

S3500-10G

S3500-26G

S3500-28G

S3500-16F

Service Ports

8*10/100/1000 Base-T ports;

2*1000 Base-X SFP ports;

24*10/100/1000 Base-T ports;

2*1000 Base-X SFP ports

24*10/100/1000 Base-T ports;

4*1000 Base-X SFP ports;

4*10/100/1000 Base-T ports (combo);

16*1000 Base-X SFP ports

8*10/100/1000 Base-T ports;

Management Port

1* Console port

Reset

N/A

1

Switching Capacity

128Gbps

256Gbps

Packet Forwarding Capacity

42Mpps

96Mpps

Operation Temperature

-20~50°C

Storage Temperature

-40~70°C

Operation Humidity

10%~90%(non-condensing)

Storage Humidity

5%~95%(non-condensing)

Dimensions

230(L)*154(W)*44(H)mm

440(L)×285(W)×44.5(H) mm

Weight

<4Kg

Input Voltage(AC)

AC:110~240V/50~60Hz

Power Consumption

<10W

<30W

LED Indicator

Power, System, Link/Act

Energy Saving

Comply with "EEE" Energy Efficient Ethernet

Item

S3500-10G

S3500-26G

S3500-28G

S3500-16F

Standards and Protocols

IEEE 802.3u,100BASE-TX

IEEE 802.3ab,1000 BASE-T

IEEE 802.3z,1000 BASE-X

IEEE 802.3ad,Static or Dynamic Link Aggregation

IEEE 802.3x,Full-Duplex Flow Control

IEEE 802.3az,EEE(Energy Efficient Ethernet)

IEEE 802.1q,VLAN

IEEE 802.1p,QoS/CoS

IEEE 802.1d,STP(Spanning Tree Protocol)

IEEE 802.1w,Rapid Spanning Tree Protocol

MAC Address Table

Up to 8K MAC addresses

32K MAC addresses

Support auto-update, two-way learning

Buffer Memory

4.2Mbit

32Mbit

Jumbo Frame

9K Bytes

10K Bytes

VLAN

Port-based VLANs

4K-entry Vlan Table

VLANs based on IEEE 802.1q

Spanning Tree

Support Spanning Tree Protocol

Support Rapid Spanning Tree Protocol

N/A

MSTP multi spanning tree

Link Aggregation

Support 8 aggregation groups, and a maximum of 8 ports in each aggregation group

Support 14aggregation groups, and a maximum of 16 ports in each aggregation group

Static aggregation and LACP

N/A

Port Mirroring

Support bi-direction port mirroring

Port Isolation

Isolation between downlink ports without influence the communication between downlink and uplink ports

Port Flow Control

Back-pressure traffic control under Half-Duplex mode

IEEE 802.3x traffic control under Full-Duplex mode

Port Rate Restriction

Port-based ingress or egress rate limiting

DHCP

DHCP Snooping

N/A

DHCP Server

Storm Suppression

Support the suppression of broadcast storm based on forwarding rate

Multicast Control

Support IGMPv1/2/3 and MLDv1/2 Snooping;

Security

Attack Prevention(Land attack\Blat attck\Ping attack\TCP control flag attrck)

MAC or Port based Security

IP ACL,MAC ACL,Vlan ACL

N/A

ARP binding

N/A

TCP/UDP port based Security

N/A

IEEE 802.1x port authentication

N/A

Radius authentication

QOS

802.1p(Port Queuing Priority)

WRR (Weighted Round Robin)

Cos/Tos, QOS

Physic Medium

10/100Base-TX:UTP category 3/4/5 cables( Maximum 100m)

1000Base-T:UTP Category 5 cable( Maximum 100m)

1000Base-SX:fiber with 850nm wavelength, supports a max transmission distance of 550m

1000Base-LX:fiber with 1310nm / 1550nm wavelength, supports a max transmission distance of 80km

Network Cable Deployment

Support Auto-MDIX function, automatically identify straight forward cable and cross-over cable

Negotiation Pattern

Support port auto-negotiation function( automatically negotiate transmission rate and Duplex modes)

Maintenance

Detect the connectivity of network cables

Uploading or downloading of the configuration data

Uploading of upgrade patch

Support system logs

WEB-based reset to factory defaults

Management

WEB-based management

CLI Management (Command Line Interface)

Telnet

SNMP
