65W/90W Poe Injector Poe++ 802.3bt Compliant

Product Description

PSE65J/PSE90J POE Injector, it's our company self-developed from Ethernet power supply product; support"IEEE 802.3af/at""POE++" POE supply;

Main Features

2 port Gigabit Rj45 network, 1GE POE out+1GE data input

Support Spherical camera, Industrial wireless AP etc.

Fluid Control: Full-duplex: IEEE 802.3x, Half-duplex: back pressure.

Auto MDI/MDIX.

Support port lightning protection.

Store-and-forward.

All ports support wire speed switch, jumbo frame transmission.

Plug and play, self-adaption.

Product Information

Model Number: PSE65/PSE90

Product Details: 1GE POE out+1GE data input

Model	PSE65	PSE90
Power pin	12+/45+ 36-/78-	12+/45+ 36-/78-
POE out	52V 1.25A	55V 1.63A
Power	65W	90W
POE	IEEE802.3af/at POE++
Data pin	12364578
Power input	AC 100-240V 50/60HZ
Shell	Metal case
Port	1GE POE output+1GE data input
Function	Plug and Play, without configuration management Under-voltage, over-voltage, over current short circuit protection System Reliability:MTBF>100k hours Comply to EN55022, CLASS BCE&RE
Environmenta	Working Temperature:0ºC~40ºC Storage temperature:-40ºC~80ºC
	Working Humidity:10%~90% RH non-condensing Storage Humidity:5%~90% RH non-condensing
Speed	Ethernet 10Mbps half-duplex, 20Mbps full-duplex Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex Gigabit Ethernet 2000Mbps full-duplex
Network Media	10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤150m) 100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤150m) 1000Base-T: Pair 4 Category 5(Cat5e) and above UTP/STP(≤150m)
Product Size	182mm72mm39mm(LWH)
Weight	0.9Kg
